4499900



ENGINE SYSTEM

  • Simpson 2.6L, T4 Final, EPA & CARB Certified
  • 3 Cylinder
  • Turbo charged, Intercooled, HPCR Fuel In jection
  • 74 (54.4 kW) PS Gross Engine Horse power @ 2000 RPM
  • 64 (47 kW) PTO Horse power @ 2000 RPM with Independent PTO

FRONTAXLE - Two Factory Options

  • 2 Wheel Drive with Telescopic Ad just ment OR
  • 4 Wheel Drive with Planetary Reduction Final Drives

POWER TRAIN

  • Transmission - 8x8 Synchro Shuttle with ComfiMesh™
    • Transmission Shift Control Lever on Right Side and Range Box Shift Control Lever on Left Side
  • Mechanical F-R Shuttle Lever Left Side of Steering Wheel
  • Outboard Planetary Final Drives
  • Brakes - Internal Multi Wet Disc with Mechanical Actuation
  • Parking Brake - Mechanical Hand Lever

PTO

  • Independent PTO, 540 RPM, 6 Spline Shaft with Lever Operated Split Torque Clutch

THREE POINT LINK AGE

  • Extendable Lower Links with Right Side Turn buckle
    • Adjustment - Category I/II Cross Drilled Ball Ends
  • Sway Chain Stabilizers

HYDRAULICS

  • Hydrostatic Steering with Separate Reservoir
  • Ferguson 3-Point Hitch System
  • 3-Point Hitch Pump Flow (4.2 GPM) *
  • Draft, Position and Response Control
  • 2 Spool Valves Included
  • Hydraulic Pump Flow 11.2 GPM at Rear Remote *
  • Maximum Hydraulic Flow 15.7 GPM (59.5 LPM) (Steering, 3-Point and Auxiliary Combined)

ELECTRICAL

  • Head lights
  • Single Rear Work Light
  • Safety Lights
  • 7 Pin ASAE Out let

OPERATORS ENVIRONMENT

  • Straddle Mount
  • Grammar Seat that Inclines as it Moves Rearward
  • Retractable Seatbelt
  • Folding ROPS
  • Suspended Foot Pedals
  • Ground-Level Fuel Tank

OTHER STANDARD FEATURES

  • Tilting One Piece Hood
  • Swinging Drawbar
  • Tool Box
  • Drawbar Clevis *

Manufacturer’s Estimate

 DocumentTaille
MF2607H.pdf
563.67 KB
